Aluminum Gate Kit Alu40 Universal DIY 6' x 6' BLACK
Aluminum Gate Kit Alu40 Universal DIY 6' x 6' BLACK
6' x 6' Universal DIY pedestrian gate kit with 4" ALU40 horizontal slats in black powder coat. The 6063-T6 aluminum frame is designed for wall-to-wall installs and includes a heavy-duty 5" HD support hinge.
- Aluminum 6063-T6
- AAMA 2604 powder coating, Black
- 6 ft wide x 6 ft high
Couldn't load pickup availability
6' x 6' Universal DIY pedestrian gate kit with 4" ALU40 horizontal slats in black powder coat. The 6063-T6 aluminum frame is designed for wall-to-wall installs and includes a heavy-duty 5" HD support hinge.
ALU40 · Universal DIY pedestrian gate
A black 6′ × 6′ single-swing aluminum gate built around the Universal DIY frame.
The ALU40 Universal DIY Aluminum Gate Kit 6′ × 6′ combines a complete aluminum gate frame, sixteen 4-inch ALU40 horizontal slats and heavy-duty support hardware in a wall-to-wall pedestrian-gate package. It is made from USA-made 6063-T6 aluminum and finished with an AAMA 2604 architectural powder coating for a modern, low-maintenance exterior system.
ALU 40 black slat pedestrian gate project
Aluglobus Universal DIY Gate System
Key Features
Built from 6063-T6 aluminum, the system offers excellent corrosion resistance while remaining lighter than many traditional steel gate systems. The powder-coated black finish gives the gate a clean contemporary appearance and is well suited for residential, contractor, coastal, humid, and demanding exterior applications.
- Universal DIY system designed for simplified assembly
- Wall-to-wall application only
- 6×6 pedestrian gate configuration
- Universal aluminum frame compatible with ALU40 gate systems
- Fully engineered frame system for strength and stability
- 4-inch ALU40 horizontal aluminum slats
- 6063-T6 aluminum construction
- Aluminum construction will not rust like conventional steel
- Designed for coastal and humid environments
- Wide lock-side frame fits most US-size lock hardware
- Super-durable powder-coated black finish
- Non-combustible aluminum metal substrate
The 6′ × 6′ Universal DIY system
See the frame, ALU40 slat system, finish and hardware from multiple angles.
Explore the Universal DIY frame, ALU40 slat system, black exterior finish and support hardware from multiple views. Open any image for a larger look without leaving the product page.
Designed around assembly
A factory-prepared aluminum gate system without welded field fabrication.
The Universal DIY platform organizes the gate around pre-engineered aluminum frame components, ALU40 horizontal slats and dedicated support hardware. The goal is a cleaner path from a verified wall-to-wall opening to an aligned finished pedestrian gate.
Built for DIY assembly
Factory-prepared components reduce the need for welded gate fabrication in the field.
Universal ALU40 platform
The frame system is shared across ALU40 gate configurations, while this SKU is supplied specifically as a 6′ × 6′ black gate.
Exterior-ready aluminum
6063-T6 aluminum and AAMA 2604 architectural powder coating support long-term exterior use.
Universal DIY system: the frame, ALU40 infill, hinge, stoppers, and supporting components are designed as a coordinated gate package to simplify assembly and reduce the need to fabricate the primary gate structure from unrelated parts.
Product specifications
The ALU40 Black 6′ × 6′ Universal DIY gate at a glance.
This listing is a black 6′ × 6′ pedestrian single-swing gate with sixteen 4-inch ALU40 horizontal slats and a complete Universal DIY aluminum frame. The standard configuration is wall-to-wall only.
Installation requirement: The standard Universal DIY configuration is wall-to-wall only. Concrete-footing installations require the appropriate HD post upgrade and must be specified for the project before installation.
| Product | ALU40 Black Universal DIY Aluminum Gate Kit |
|---|---|
| SKU | 26834 |
| Gate type | Pedestrian / single-swing aluminum gate |
| Finished size | 6′ wide × 6′ high |
| Material | USA-made 6063-T6 aluminum |
| ALU40 slats | 16 pieces · 4″ × 6′ horizontal aluminum slats |
| Finish | Architectural powder coating |
| Coating standard | AAMA 2604 |
| Paint brands | Cardinal Paint / TIGER |
| Standard color | Black |
| Custom colors | Available upon request |
| Lock planning | Wide side frame fits most U.S.-size lock hardware |
| Combustibility | Non-combustible aluminum substrate |
| Ignition behavior | Does not burn under normal fire conditions |
| Melting point | Approximately 615–655 °C |
| Smoke developed | 0 |
| Installation | Wall-to-wall installation only |
| Concrete footing | Not included · HD post upgrade required |
| DIY skill level | Intermediate |
| Tools | Not included |
| Country of origin | Made in the USA |
ALU 40 black slat pedestrian gate project
What’s included
A coordinated 6′ × 6′ gate package built around the Universal DIY frame.
The product listing combines the frame, gate stops, hinge support and sixteen black ALU40 slats into one pedestrian-gate package. Fully DIY frame design exclusive to Aluglobus.
Complete aluminum gate frame
The Universal DIY frame creates the single-swing gate structure without requiring welded field fabrication.
Wide lock-side frame
The wider side frame is designed to accommodate most U.S.-size lock hardware so the latch and handle can be planned into the gate.
Top and bottom frame
Factory-prepared top and bottom frame components complete the Universal DIY gate perimeter.
Gate T-stopper
A coordinated T-stopper is included for the finished closing condition.
Receiver L-stopper side component
The receiver-side component supports clean wall-to-wall closure and lock-side planning.
5″ HD support hinge · Qty 1
One heavy-duty 5-inch support hinge is included. For true self-closing operation, a compatible hydraulic spring is recommended and sold separately.
16 black ALU40 slats
Sixteen 4″ × 6′ powder-coated 6063-T6 aluminum slats create the horizontal infill.
What is not included
Concrete footing, lock hardware, hydraulic self-closing spring and installation tools are not included with the standard kit.
Optional posts and caps
Post and cap options are selected separately when the project requires them. Concrete-footing conditions require the correct HD post configuration.
Why this 6′ × 6′ configuration
Six feet of width and height with a clean horizontal ALU40 rhythm.
At six feet wide and six feet high, this configuration creates a substantial pedestrian entry for front yards, side yards, courtyards and suitable light-commercial access points. The horizontal 4-inch ALU40 slats give the gate a broader architectural rhythm than narrower-slat systems, while the full aluminum frame keeps the design visually contained.
- 6′ × 6′ pedestrian format
- Single-swing operation
- 16 horizontal ALU40 slats
- Black architectural finish
- 6063-T6 aluminum
- Non-combustible substrate
- DIY-oriented assembly
- Wall-to-wall configuration
Why ALU40: the wider 4-inch horizontal profile creates a stronger architectural rhythm than narrower slat systems, giving the finished gate a clean, substantial appearance.
More product views
Additional views of the ALU40 6′ × 6′ gate system.
Open any image to inspect additional product views in the built-in lightbox without leaving the product page.
ALU40 profile geometry and the 6′ × 6′ Universal DIY gate layout
Use these drawings to understand the ALU40 profile and the gate-kit component relationship. Final opening conditions, mounting surfaces and hardware placement must still be verified for the actual installation.
ALU40 Universal DIY hardware and parts
Understand the frame, receiver hardware, ALU40 slats and support components before assembly.
The Universal DIY package combines the gate frame, receiver-side components, ALU40 slat material and heavy-duty hinge support. Optional post and cap selections remain separate so the project can be matched to the actual mounting condition.
Universal gate frame
Complete aluminum frame with wide lock side, top and bottom frame components for the 6′ × 6′ single-swing gate.
Receiver and striker side
Gate T-stopper and receiver L-stopper components support the finished closing condition and lock-side alignment.
ALU40 slat package
Sixteen 4″ × 6′ black powder-coated 6063-T6 aluminum slats are listed with this kit.
5″ HD support hinge
One heavy-duty support hinge is included. A hydraulic closer or spring is a separate selection when true self-closing operation is required.
Optional HD post upgrade
The standard gate is wall-to-wall. Projects that require concrete footing must use the correct HD post upgrade instead of assuming posts are included.
Optional posts and caps
Additional posts and matching caps can be selected separately from the product-page options when the project condition requires them.
ALU 40 black slat pedestrian gate project
Applications
Built for pedestrian openings where a modern aluminum gate and low routine maintenance matter.
The 6′ × 6′ format is suited to residential and light-commercial pedestrian applications when the opening and wall-to-wall support conditions match the Universal DIY system.
Front pedestrian entries
Create a substantial modern entrance with six-foot height and broad horizontal aluminum lines.
Side-yard gates
Use the six-foot-wide pedestrian leaf where the property needs more passage width than a narrow walkway gate.
Courtyards and entryways
Coordinate the black gate with contemporary walls, fence systems and exterior architecture.
Privacy-oriented entries
The 4-inch horizontal ALU40 layout creates a strong architectural rhythm for private residential spaces.
Light-commercial pedestrian access
A practical aluminum option for pedestrian-only openings with suitable structural mounting conditions.
Coastal and humid climates
Aluminum does not develop iron-oxide rust like steel and is well suited to environments where corrosion maintenance is a concern.
Durability and finish: 6063-T6 aluminum, architectural powder coating and no iron-oxide rust
The frame and ALU40 slats use 6063-T6 aluminum with an AAMA 2604 architectural powder-coated finish. The aluminum substrate does not rust like iron-based metal and will not rot, swell or splinter like wood.
| 6063-T6 aluminum | Architectural aluminum used throughout the listed gate system. |
|---|---|
| AAMA 2604 finish | Architectural coating performance for exterior color retention and surface protection. |
| Non-combustible substrate | The aluminum material itself does not ignite or sustain flame under normal fire exposure. |
Material performance: the structural gate components are aluminum. Project-specific requirements for the complete assembly, hardware, finish, clearances, and surrounding materials should be confirmed where applicable.
Assembly sequence
A six-step path from verified opening to aligned single-swing gate.
This standard SKU is designed for wall-to-wall mounting. Start with the opening and structural mounting surfaces, then assemble and align the gate around the actual site condition.
Verify the opening
Measure the opening at the top, middle and bottom and confirm the wall-to-wall mounting surfaces are plumb, solid and suitable for the gate hardware.
Lay out the Universal frame
Place the frame components on a protected flat surface, confirm orientation and keep the assembly square as the frame comes together.
Install the 16 ALU40 slats
Install the sixteen 4-inch horizontal slats consistently according to the supplied system instructions and ordered gate configuration.
Set hinge hardware
Position the 5-inch HD support hinge for the required swing direction and verify the hinge-side structure can support the assembled leaf.
Set the receiver side
Align the receiver-side components, T-stopper, L-stopper and selected lock hardware for clean closure.
Align and test
Check clearances, fasteners, latch engagement and smooth swing through the full arc before regular use.
Buying and installation guide: confirm the opening, swing, lock hardware and support condition before assembly
The Universal DIY system reduces fabrication work, but a six-foot-wide pedestrian leaf still depends on accurate site conditions and correct hardware planning.
Measure wall to wall
Confirm the finished opening at multiple heights and account for hinge, latch and receiver-side clearances.
Confirm the listed size
This SKU is supplied as a 6′ × 6′ gate. Do not assume the frame should be cut to an arbitrary size without confirming the correct configuration with Aluglobus.
Confirm swing direction
Plan the hinge side and swing direction around clearance, traffic flow and the actual opening.
Plan lock hardware
Confirm the selected latch or lock body and required clearances before finalizing the lock-side setup.
Check self-closing needs
If true self-closing operation is required, select the appropriate hydraulic spring or compatible closing hardware separately.
Confirm mounting condition
The standard configuration is wall-to-wall. Concrete-footing projects require the correct HD post upgrade before installation.
Wall-to-wall installation: verify finished opening dimensions, structural mounting surfaces, hinge orientation, swing clearance, lock hardware, stoppers, and site conditions before assembly and installation.
Product videos
See the Universal DIY gate system in motion.
Watch the Universal DIY gate system and ALU40 gate footage for a closer look at the aluminum profiles, assembly approach and finished design language.
Frequently asked questions
Answers before you assemble the 6′ × 6′ gate.
Common questions about the package, aluminum construction, wall-to-wall installation, finish, hardware and ALU40 system.
What is included in the ALU40 Universal DIY 6′ × 6′ kit?
The listing includes the complete aluminum gate frame, wide lock-side frame, top and bottom frame, gate T-stopper, receiver L-stopper side component, one heavy-duty 5-inch support hinge and sixteen black 4-inch by 6-foot ALU40 horizontal slats.
Is the aluminum gate rust-resistant?
Yes. The 6063-T6 aluminum does not develop iron-oxide rust like steel. The AAMA 2604 architectural powder coating adds exterior surface protection. Routine cleaning is still recommended, especially in coastal environments.
Can I install the gate myself?
The system is designed for DIY assembly and is listed at an intermediate DIY skill level. Accurate measurement, frame squaring, drilling, fastening and hinge alignment are still important.
Can I modify this 6′ × 6′ kit to any other size?
This SKU is supplied as a 6′ × 6′ gate. The Universal platform is used across multiple ALU40 gate sizes, but do not assume this specific kit should be cut or changed to an arbitrary dimension. Confirm the correct size or custom configuration with Aluglobus before altering components.
How long will the powder-coated finish last?
The gate uses an AAMA 2604 architectural powder-coated finish intended for exterior exposure. Actual appearance over time depends on climate, cleaning, physical wear and site conditions.
Does the wide side frame accept common lock hardware?
The product listing states that the wide side frame fits most U.S.-size lock hardware. The lock itself is not included, so confirm the selected lock body and installation requirements before assembly.
Can the standard gate be installed with posts set in concrete?
Not in the standard configuration. This Universal DIY gate is listed for wall-to-wall installation only. A concrete-footing condition requires the appropriate HD post upgrade and should be specified before installation.
Can the gate be self-closing?
The heavy-duty support hinge is listed as self-closing capable, but the product page recommends a hydraulic spring for true self-closing operation. That spring is sold separately.
Are installation tools included?
No. Installation tools are not included. The exact anchors, drill bits and fastening hardware required can vary with the wall or structural mounting surface.
Reference
Product views & drawings
Show 2 product views and drawings
Ready to order?
Buy the listed 6′ × 6′ kit, or verify the opening first.
If the opening is already confirmed as a compatible wall-to-wall 6′ × 6′ condition, proceed with the listed gate. If not, send the opening dimensions and photos before ordering.
Project checkpoint: do not guess on a 6-foot-wide single leaf.
Before assembly, make sure the opening and support conditions match the Universal DIY system.
- Finished opening width + height
- Wall-to-wall support condition
- Hinge side + swing direction
- Bottom and side clearances
- Latch / lock requirement
- Photos from both sides of the opening
- Project city / state
Choose your next step
Confirm the fit first, or order the listed 6′ × 6′ kit.
For nonstandard openings, concrete-footing conditions or uncertainty about the hinge and receiver sides, send the project information before ordering. For a verified standard wall-to-wall condition, purchase the listed kit directly.
